WA-400HI

Compressed air cleaner wellair-HI series

Medium pressure auto drain type for use up to 1.6 Mpa (16 kgf/㎠).

Maximum operating flow rate 400 (Nl/min).
Operating pressure range 0.1~1.6(Mpa)
Guaranteed pressure resistance 2.5 (Mpa)
Fluid temperature 5~65(°C)
Condensate outlet connection diameter 1/4 (Rc)
Air pipe connection diameter 3/8 (Rc)
Weight 1.10(kg)
