WA-2500RE

Compressed air purifiers wellair-RE series　

Equipped with heavy duty auto drain. More powerful drainage of dusty and oily condensate.　

Maximum operating flow rate 2500 (Nl/min).
Operating pressure range 0.1~1.5(Mpa)
Guaranteed pressure resistance 1.5(Mpa)
Fluid temperature 5~65(°C)
Condensate outlet connection bore 1 (Rc)
Air pipe connection diameter 3/8 (Rc)
Weight 13.10(kg)
